Air Cooling Hot Splicing Press For PU Belt Jointing Machine For Belt Width 600

The hot splicing joint conveyor belt joint has proved to be the most ideal joint method in many years of actual combat, which can ensure high joint efficiency, and is also very stable, the joint life is also very long, and it is easy to master.

Detailed Images:

Air Cooling Hot Splicing Press For PU Belt Jointing Machine For Belt Width 600 is an all-in-one solution for splicing thermoplastic conveyor belts (e.g. PVC polyurethane). No external control box, air pump, or water cooling tank are required.

The presses are provided with electric heating and built in air cooling. The jointing process runs fully automated

Features:

• Temperture Controller for upper and lower heating platen from Omron(Japan), Time Controller from CHNT.
•

• The splice surface is 130 mm ; the heated zone is 110 mm.
•

• The bottom heating can be set lower or higher than the top heating
•

• For thicker belts a preheat temperature and preheat dwell time can be applied
•

• Cooling down to the cooling temperature (safe temperature to take the belt out)
•

• Keeping it at the splice temperature (adjustable dwell time)
•

• Heating up to a splice temperature of max. 200°C (392°F)
•

• Splice pressure is applied by an internal compressor, max. 2 bar (28 psi)
•

• Temperature error (Up and bottom hot platen) is less than 3 ºC, heating more uniformer.
•

• Laser silica gel hot platen, better than manual type.

If the belt is relatively thick a problem might occur where the outside of the belt is at the splicing temperature too long, waiting for the inside to reach the required temperature. Molten material might flow away or discolor and fabrics might shrink. To avoid this problem from happening, the preheat option can be used. This option heats the belt up (outside and inside) to a temperature just below the melting temperature. After the preheat stage, the inside splice temperature can be reached much quicker, minimizing the risk for unwanted flow of material, discoloring or fabric shrinkage.

The reading of the display relates to the top temperature of the press. If more or less heat is required at the bottom of the belt, the "bottom heat factor" can be used. Please note that this factor relates to a plus or minus amount of heat (%), not to a specific temperature.

.

Air Cooling Hot Splicing Press For PU Belt Jointing Machine For Belt Width 600 also called conveyor belt vulcanizing press or belt vulcanizing press machine. It's vulcanize equipment and tools for repairing & splicing of conveyor belt. It suits for various conveyor belt, such as EP, Rubber, Nylon, Canvas and Steel cord belt, etc.
The belt vulcanizer is dependable, lightweight and portable machine, which is widely used in the field of metallurgy, mining, power plants, ports, building materials, cement, coal mine, chemical industry, etc. Heating plates are available for rhombic, rectangular and modular type (two or more sets of heating plates together).

Specifications:
•Running ACP series air cooled press,have different models from 300mm to 2100mm.
•Used for PVC/PU/PVK Belt and thermoplastic belt materials etc.
•Portable splice press,light weight and with flight case as standard packing,easily removed to anywhere for on-site joint work.
•Fast Splicing:Heating and cooling time:no more than 12mins.
•All-in-one design:Integrated air cooling system and also air compressor inside.To ensure that belt is quickly cooled down and auto press on,without water pump or additional air compressor.The air compressor made in Germany.
•Reliable and automatic temperature control with time controlling(in one meter,also you can sent by yourself).High quality Euro thermistor.The temperature controller from Eurothern,made in UK.
•Air pressure controller (set the air pressure and display the current pressure),High quality SMC Controller.

Machine specification of Air Cooling Hot Splicing Press For PU Belt Jointing Machine For Belt Width 600

The PA series air cooled press, have different models for width from 24″ (300 mm) to 84″ (2100 mm)

Specification list

Functions of Air Cooling Hot Splicing Press For PU Belt Jointing Machine For Belt Width 600

• Splice pressure is applied by an internal compressor, max. 2 bar (28 psi)

• Heats up to a splice temperature of max. 200°C (392°F)

• Keeps it at the splice temperature (adjustable dwell time)

• Cools down to the cooling temperature (safe temperature to take the belt out)

• For thicker belts a preheat temperature and preheat dwell time can be applied

• The bottom heating can be set lower or higher than the top heating

• The splice surface is 130 mm ; the heated zone is 110 mm.

Introduction of Air Cooling Hot Splicing Press For PU Belt Jointing Machine For Belt Width 600

If the belt is relatively thick a problem might occur where the outside of the belt is at the splicing temperature too long, waiting for the inside to reach the required temperature. Molten material might flow away or discolor and fabrics might shrink. To avoid this problem from happening, the preheat option can be used. This option heats the belt up (outside and inside) to a temperature just below the melting temperature. After the preheat stage, the inside splice temperature can be reached much quicker, minimizing the risk for unwanted flow of material, discoloring or fabric shrinkage.

The reading of the display relates to the top temperature of the press. If more or less heat is required at the bottom of the belt, the “bottom heat factor” can be used. Please note that this factor relates to a plus or minus amount of heat (%), not to a specific temperature.

Packing&Delivery of Air Cooling Hot Splicing Press For PU Belt Jointing Machine For Belt Width 600
We will use film to wrap the machine. then put into wooden box.
The normal package is wooden box.(Fumigation treatment).
