Electric Heating Water Cooling Rubber Conveyor Joint Belt
Vulcanizing Machine
Salient Features
1. Made of aluminum alloy, light weight,
2. Easy installation and removal, easy to handle.
3. Suppress water bag:
1) Light weight, it is the 1/4 weight of the ordinary.
2) Large expansion amplitude.
3) Uniform pressure and the pressure can reach 3.0MPa.
4) No water leakage and long life.
4. Automatic temperature control and timing.
Conveyor belt hot vulcanization joint method is the most commonly used method in belt joints. This kind of
conveyor belt joint is bonded on site by Rubber Conveyor Belt Hot Vulcanizing Rubber Belt Vulcanizing
Machine which is less affected by the environment and has a long joint
life.
Electric Heating Water Cooling Rubber Conveyor Joint Belt
Vulcanizing Machine
1. Voltage: 220V 380V 415V 525V 660V 1140V 50HZ 60HZ(Customize
available according to your requirement)
2. Quick water cooling device: 15 minutes From 145 ºCdown to 80
ºCor even lower
3.Cooling source: Water or Air
4.Heating source: Electricity
5. Heating time: from room temperature to vulcanization temperature
need less than 20 minutes
6. Heating plate surface temperature difference: ± 1 ºC
7. The temperature adjustment range: 0 ~ 200 ºC(custom)
8. Vulcanization pressure: Max 2.5MPa.
9. Curing temperature: 0 ~ 99min (according to the thickness of the
belt to adjust)
Usually 10mm~25mins, 20mm~35mins
10. Automatic mute pressure pump
11. Automatic control panel: insulating and waterproof, security
alarm, Auto power-off when reach the vulcanization temperature.
Upgrading explosion proof control box option available.
Machine specification of Electric Heating Water Cooling Rubber Conveyor Joint Belt
Vulcanizing Machine
| Model | Belt Width (mm) | Power(kw) | Dimensions (L*W*H mm) | Weight(kg) | Single Piece Weight(kg) |
|
| ZLJ-650*830 | 650 | 9.5 | 1370*830*630 | 430 | 45 |
| ZLJ-650*1000 | 10.8 | 1370*1000*630 | 500 | 66 |
| ZLJ-800*830 | 800 | 11.2 | 1520*830*630 | 535 | 70 |
| ZLJ-800*1000 | 13.5 | 1520*1000*630 | 575 | 79 |
| ZLJ-1000*830 | 1000 | 14.1 | 1720*830*630 | 595 | 82 |
| ZLJ-1000*1000 | 15.7 | 1720*1000*630 | 620 | 95 |
| ZLJ-1200*830 | 1200 | 16.5 | 1920*830*710 | 800 | 96 |
| ZLJ-1200*1000 | 17.2 | 1920*1000*710 | 870 | 113 |
| ZLJ-1400*830 | 1400 | 18.6 | 1930*830*760 | 930 | 107 |
| ZLJ-1400*1000 | 20.7 | 2120*1000*760 | 1180 | 132 |
| ZLJ-1600*830 | 1600 | 21.5 | 2320*830*800 | 1270 | 120 |
| ZLJ-1600*1000 | 22.3 | 2320*1000*800 | 1460 | 146 |
| ZLJ-1800*830 | 1800 | 23.3 | 2520*830*850 | 1380 | 137 |
| ZLJ-1800*1000 | 25.6 | 2520*1000*850 | 1650 | 164 |
| ZLJ-2000*830 | 2000 | 27.2 | 2720*830*950 | 1760 | 154 |
| ZLJ-2000*1000 | 30 | 2720*1000*950 | 1860 | 182 |
| ZLJ-2200*830 | 2200 | 29.2 | 2920*830*950 | 1860 | 165 |
| ZLJ-2200*1000 | 34.1 | 2920*1000*950 | 1970 | 198 |
Our Electric Heating Water Cooling Rubber Conveyor Joint Belt
Vulcanizing Machine
use new designed water pressure bladder for pressurizing, it is made of rubber material, has better
performance and longer service life.
Package of lightweight conveyor belt joint vulcanizing machine:
Please don't hesitate to contact us if you have any questions on
conveyor belt jointing questions.
